Gantry Robot System

Here are products and the list of the business achievements of DM Technology.

Business Achievement

Home Business Achievement Gantry Robot System

Engine Head
Engine Block
Valve Body
Convert housing
TM Case
Bed Plate
Tire Wheel
Knuckle
Disk
Shafts
Gears
Covers
Others

Engine Head

Tau engine head automation line

Outline of line constitution

Installation length: 200,000mm
Equipment constitution: GANTRY-SP300/AP200 (4-LINE)
Important options/ Features

-5-AXIS ( H-TYPE )
-In-out systems for carrying in and carrying out products

General Specification

Work: Four kinds of T engine heads (3.5,4.0,4.6)
Customer: Hyundai Motor
Capacity: 50,000/year
Gantry robot system

VIDEO

Gantry Robot System

Engine Block

Tau engine block automation line

Valve Body

Valve body line gantry robot system

Gantry robot head ass’y

Valve body gripper ass’y

Peripheral devices – IN Stocker

Convert housing

Convert housing gantry automation line

Outline of line constitution

Installation length: 40,000mm
Equipment constitution: GANTRY-SP300/AP200 (4-LINE)
Important options/ Features

-3-AXIS ( H-TYPE )
-In-outsystems for carrying in and carrying out products

General Specification

Work: 6-shift converter housing
Customer: Daelim Motor, Dongnam Precision Beijing
Capacity: 300,000/year

TM Case

New generation & next generation TM case line

Outline of line constitution

Installation length: 25,000mm
Equipment constitution: Gantry-SP300/AP166
Important options/ Features

– 3-AXIS ( H-TYPE )
– In-outsystems for carrying in and carrying out products
– Independent inspection equipment

General Specification

Work: TM cases
Customer: Konec
Capacity: 100,000/year

Bed Plate

Bed plate automation line

Outline of line constitution

Installation length: 25,000mm
Equipment constitution: GANTRY-SP250/AP166 (2-LINE)
Important options/ Features

– 3-AXIS ( H-TYPE )
– In-outsystems for carrying in and carrying out products
– Delivery date: October in 2005
– Delivery period: 3 months

General Specification

Work: Bed plates
Customer: Daeseung Precision
Capacity :

Tire Wheel

Tire wheel automation line

VIDEO

Knuckle

Knuckle line gantry robot system

Gripper

In stocker & NG emission

Disk

Disk line gantry robot system

Shafts

Crankshaft processing automation line

Outline of line constitution

Installation length: 13,500mm /7,500mm
Equipment constitution: Gantry-SP250/AP110 (2-line)
Important options/ Features

– 3-axis(gripper rotation using servo)
– Medium buffer / Independent inspection stand
– In-outsystems for carrying in and carrying out products
– Delivery date: March in 2006
– Delivery period: 3 months

General Specification

Work: Crankshafts (2 kinds)
Customer: GM Korea
Capacity: 100,000/year

Cam shaft & Crank shaft line gantry robot system

Gantry head ass’y

Gears

GEAR-TRANSFER DRIVEN LINE

Outline of line constitution

Installation length: 5 lines including 30,000mm
Equipment constitution: Gantry-SP200/AP110,AP80 (5-line)
Important options/ Features

– 2-AXIS ( I-TYPE )
– In-outsystems for carrying in and carrying out products
– Turn & shift, washing devices, NG dischargers

General Specification

Work: Components of 6-shift transmissions
Customer: Wistco
Capacity: 250,000/year

Gear – Transfer line gantry robot system

Head

Gripper

Measuring instruments & demagnetizers &in stockers

Covers

Cylinder head cover automation line

Outline of line constitution

Installation length: 17,000mm
Equipment constitution: GANTRY-SP150/AP80 (2-LINE)
Important options/ Features

– 3-AXIS ( H-TYPE )
– In-outsystems for carrying in and carrying out products
– Delivery date: December in 2005
– Delivery period: 2.5 months

General Specification

Work: 2 kinds of lambda cylinder head covers (LH, RH)
Customer: Daelim Motors
Capacity: 50,000/year

Gantry head & Gripper ass’y

Oil pump cover in stocker

Shape steel cutting, sub-material labeling,
supplying devices

Sub-material labeling automation line

Outline of line constitution

Installation length: 30,000mm /11,500mm
Equipment constitution: 3-axis shipbuilding sub-material markers
Important options/ Features

– 3-axis(material marking system using servo)
– Iron plate transportation conveyor
– In-outsystems for carrying in and carrying out materials

General Specification

Work: Shipbuilding sub-materials (iron plates)
Customer: Samsung shipbuilding
Capacity :
